| 詳細信息 |
| 該設備屬于高速機， 正在修復中，準備更換的系統為西門子840D
Hurco BMC-2416 Vertical Machining Center Ref #: 3121 Model #: BMC2416 Mfg: 1999 installed 2000 Specifications: Table ........................................... 29.5" x 15.7" Max Load on Table ................... 760 lbs Travels, X-Axis ........................... 24” Travels, Y-Axis ........................... 16” Travels, Z-Axis ........................... 22” Main Motor ................................. 10 HP Spindle Speed .......................... 80 - 8,000 RPM Spindle Axis Torque/RPM ….. 100 ft-lb / 500 (30 min) Spindle Taper ............................ CAT 40 ATC .............................................. 24 (Swing Arm) Rapid Traverse ……….….……. 945 IPM (X,Y) Rapid Traverse ……….….……. 590 IPM (XZ) Max Thrust Rating …….….…... 1450 lbs. (X,Y) 2490 (Z) Operating Dimensions ……….. 139" W x 135" D x 103" H Shipping Dimensions ………… 89" W x 116" D x 96" H Machine Weight …..………….. 9,040 lbs Equipped With: - Ultimax III Split Screen Conversational Control - Graphics - Floppy Drive - Chip Auger - All Manuals |
|
|
